MATISX Dual IRIS Scanner

MATISX is a robust, portable and easy-to-use dual iris scanner device; use to carry out IRIS authentication of both the iris of any human with higher precision and greater speed.

Get In Touch

Our MATISX Dual IRIS Scanner

Mantra’s MATISX is an adjustable interpupillary & easy-to-operate dual-iris scanner device used to capture the double iris images of an individual simultaneously. Designed with an advanced biometric technology, MATISX is the next-generation iris scanner device compliant with ANSI NIST and ISO image interchange format. The innovative dual iris scanner MATISX offers ease of convenience, high reliability and long-lasting durability. The dual iris sensor presents multiple compelling functionalities such as auto capture feature for quick & effortless dual iris recognition, adjustable interpupillary distance range, immunity to ambient lighting and much more.

Benefits

Portable

Robust

Easy-to-operate

Durable

Highly Reliable

Our Specifications

High-resolution imaging and user-friendly interface, designed for varied environments.

IRIS Sensor

Simultaneous Capture :

Dual IRIS Capture

IRIS Diameter :

> 210 Pixel

Spatial Resolution :

> 60 % @ 4.0 Lp/mm

Pixel Resolution :

> 20 Pixel/mm

Image Margins :

Left & Right >=0.5x IRIS Diameter, Top & Bottom >=0.25x IRIS Diameter

Pixel Depth :

8 Bits/Pixel (256 Gray Level)

Imaging Wavelength :

700 - 900 nm

Frame Rate :

>=10 Frames/Sec

Scan Type :

Progressive

Sensor SNR :

> 36 dB

Capture Mode :

Auto Capture with Built-in Quality Check

Illumination :

Near Infra Red (NIR)

Capture Distance :

100mm from the Front of Camera mirror

Capture Volume (WxHxD) :

30 x 22.5 x 15 mm

Exposure Time :

< 33ms

Hardware

Interface :

USB2.0 High Speed (USB-IF Certified)*

Operating Voltage :

5V +/- 5%

rowspan="2">Current Consumption :

Operating :- < 350 mA (Max)
Stand By :- < 160 mA (Max)

Operating Temperature :

0 to 50 °C

Operating Humidity :

10-90% RH, Non-Condensing

ESD Protection :

+/-4kV (Contact Discharge), +/-8kV (Air Discharge)

Device Dimension :

185 x 145 x 62 mm

Device Weight :

0.41Kg

Platform

Operating System :

Windows x86 and x64, Linux

Certifications*

Biometric Data Interchange Format :

ISO 19794-6 for IRIS Image, ISO 29794-6 for image quality

EMI / EMC Compliance :

CE & FCC Part 15B Class B*

Environmental, Health and Safety :

RoHS*

Safety :

Exempt Group per IEC 62471:2006-07, IS13252 (Part 1)*

Ingress Protection Rating :

IP65*

Device Driver :

WHQL Certified
