Get In TouchThis industrial multi-modal terminal is designed with face and optical finger sensors to serve industrial use cases and is powered by the most advanced facial and finger matching engine along with Face, Finger it also supports PIN based verification. The terminal can handle a variety of industrial USE CASES, including visitor management, attendance, access control.
Mode of Authentication
PIN
Fingerprint
Facial
Discover the BioNIC FPX, an advanced biometric attendance system that uniquely combines facial recognition and fingerprint scanning technologies. This powerful integration ensures a dual layer of security and precision in tracking employee attendance, making it a robust solution for businesses aiming to enhance both accuracy and efficiency.
The BioNIC FPX elevates workplace attendance systems by offering a blend of the most trusted biometric technologies. It's designed to provide a seamless and secure method for recording attendance, making it ideal for organizations looking for a comprehensive approach to managing employee timekeeping.
Key Features of the BioNIC FPX Biometric Attendance System:
Dual Biometric Verification:
With both facial recognition and fingerprint scanning, the BioNIC FPX provides flexible and highly secure options for employee check-ins, drastically reducing the chances of time theft or buddy punching.
Enhanced Security Measures:
The combination of face and fingerprint data offers a heightened level of security, ensuring that only registered employees can access the premises and record attendance.
User-Friendly Interface:
The system is equipped with an intuitive interface that simplifies the check-in process, making it quick and easy for employees to use without requiring extensive training.
Seamless Integration:
Integrate the BioNIC FPX smoothly with existing HR and payroll systems to automatically sync attendance data, enhancing administrative efficiency and accuracy.
Robust and Reliable Design:
Built to perform in various environments, the BioNIC FPX is durable enough to handle the demands of both office settings and more challenging industrial areas.
The BioNIC FPX is perfect for organizations that require a reliable, secure, and easy-to-use attendance tracking system. By leveraging the strengths of both facial and fingerprint technologies, it ensures that managing employee attendance is as efficient as it is secure. Ideal for any business, from small startups to large corporations, the BioNIC FPX stands out as a leader in modern attendance management solutions.
Some of the significant features of our advance biometric fingerprint scanner device are listed underneath:-
IP54
Fingeprint Scanner
Liveness Check Passed
Dual RGB and Near Infrared Camera 2 Million WDR Pixel Resolution
2.2GHz Quad core ARM Cortex-A73
2GB RAM + 16GB EMMC
ISO14443 Type A/B Cards, Mifare Classic / Desfire
5 Inch, Vertical Screen H1080 * W1920 Resolution Multi point capacitive touch screen with tuffen glass
Face & Fingerprint Recognition System - Redefining the Access Control system.
Feature exquisite specifications that are designed to address the modern-day requirements of individual identification and authentication.
CPU :
2.2GHz Quad core ARM Cortex-A73 and 1.8GHz dual core Cortex-A53
GPU :
ARM G52 MP4 GPU
Display :
5 Inch, 1080X1920 Resolution, Full view IPS TFT Display
Touch :
Multi point capacitive touch screen with tuffen glass
RAM :
2GB
Storage :
16GB
Camera Type :
Dual RGB and Near Infrared Camera
Pixel Resolution :
2M (1920 x1080)
Frame Rate :
30 FPS
Minimum Illumination :
= 0.1 LUX
Dynamic Range :
= 45dB Linear & = 100 dB HDR supported for various light environment
Focus Distance :
30 -150 cm
White Balance :
Auto
Photo Flood Light :
Visible & IR dual Flood Light
Support :
Live Face Detection
Network Module :
1x RJ45, 10M/100M
Wi-Fi / BT :
Supported
Audio :
Supported
HDMI :
1 X HDMI
RS232 :
1 x RS232
RS485 :
1 x RS485
Wiegand Interface :
1 x Output ; 1 x Input
Relay Interface :
2 x Relay (NC, NO, COM)
Power Jack :
DC 5V/3A
GPIO's :
5 X GPIO
RTC :
Supported
GPRS/3G/4G (Optional) :
Supported
Fingerprint Type :
Scratch Free Optical Sensor
Fingerprint Image :
316 x 354 Pixels ( 16 mm x 18 mm )
Image Specs :
500DPI, 8 Bit Grayscale
Certifications :
CE, FCC, RoHS, STQC, PIV, IEC60950, IS13252 Part
Contactless Card (Optional) :
ISO14443 Type A/B Cards, Mifare Classic / Desfire
Face Detection :
Support multiple people detection and tracking
Face Database Capacity :
10000 / 50000
1:N Face Recognition :
Supported (5K, 10K, 20K, 50K)
1:1 Face-matching :
Supported
Stranger Detection :
Supported
Face Recognition Accuracy :
Normal Light Condition > 99.9%
External Light Condition > 95%
Liveness Detection :
Supported
Recognition Speed :
300 ms
Operating System :
Customized Android
SDK :
Appropriate SDK for all accessories to be provided for Android
Casing :
Light weighted oxidised aluminium alloy back cover for heat dissipation with ABS front cover
Protection Grade :
Dust Proof
Operating Temperature :
-10℃ ~ 60℃
Storage Temperature :
-20℃ ~ 60℃
Operating Humidity :
10%-90% RH (Non-Condensing)
Dimensions :
185.0 x 97.0 x 30.5 mm
Weight :
Approx 800 gm
Mounting Type :
Wall mount, Turns Tile Mount
Certifications :
CE, RoHS, BIS
Comprehensive user guides and informative brochures available, providing a detailed overview and usage instructions.
