BioNIC 8 Biometric Access Control System for Advanced Level of Security

Mantra Bionic8 is the most advanced fingerprint and smart card reader terminal featuring next-generation biometric technology and security platform. Bionic8 provides class-leading performance through the world’s best matching performance, uncompromised security, and accuracy along with top-notch usability.

Get In Touch

Our BioNIC 8

Introducing the BioNIC 8, a revolutionary biometric access control system designed with a deep understanding of the needs of modern enterprises. This system is not just about enhancing security; it's about integrating it seamlessly into the daily rhythms of your workplace. The BioNIC 8 combines state-of-the-art security technology with an intuitive, user-friendly interface, making secure access a smooth and natural part of your day.

It is a wall-mounted biometric tablet with BOSS ( Bharat operating system), featuring biometric fingerprint identification, smart card reader to provide multiple functions for various customer applications. It can be deployed in a wide variety of environmental conditions. It is specifically designed for mounting on surfaces used in indoor or outdoor places. It also has an inbuilt battery that can handle long hours of intense usage along with it has IP65 water & dustproof capability and has met the IEC sealing standards.

The BioNIC 8 redefines the access control security system. It exceeds basic functionality by providing a system that values ease of experience and operational effectiveness.


Key Features of the BioNIC 8 Biometric Access Control System:

Advanced Biometric Technology:

Utilizing the latest advancements in fingerprint and facial recognition, the BioNIC 8 offers precise and swift identity verification, ensuring that only authorized personnel can enter sensitive areas.

Unobtrusive Security:

The BioNIC 8 enhances safety without creating barriers. It's designed to be inviting and reassuring, providing top-level security that supports a welcoming environment.

Ease of Use for Everyone:

With simplicity at its core, the BioNIC 8 features a straightforward interface that only an authorized person can navigate effortlessly, making it a secure access control system.

Durable and Adaptable:

Engineered for reliability, the BioNIC 8 performs consistently across a variety of settings, ensuring dependable operation wherever it's needed.

Effortless Integration:

This system seamlessly melds with your existing security infrastructure, bolstering your capabilities without the hassle of a major overhaul.


The BioNIC 8 is the ideal solution for any organization that values security as much as it values efficiency and user engagement. Whether you're managing a bustling corporate office, a sensitive government facility, or an institutional campus, the BioNIC 8 ensures that every interaction with your security system is as reassuring as it is effective.

Features

Some of the significant features of our advance biometric fingerprint scanner device are listed underneath:-

Rugged design; IP65 Sealing.

User Friendly design offers Intuitive User Experience; Ultrafast User Identification.

Ultrafast User Access and Higher Security

Secure eMMC boot; On board 16GB offers Higher Capacity to Manage User & Events.

In-built Secure Access Module; supporting ISO7816 compliant Contact Smart Card

Contactless Smart Card Module; supporting ISO14443 compliant Contactless Smart Card

Tamper Detection and Protected.

Battery Operated Devices with back-time of 5 hours.

Multi Finger Capacitive touch display with Scratch proof Gorilla Glass.

Specification

Feature exquisite specifications that are designed to address the modern-day requirements of individual identification and authentication.

Hardware & System

CPU :

ARM Cortex®-A7 core, 528MHz & Upgradable to ARM Cortex®-A9 core, 1.0 GHz

Memory :

512MB RAM & Upgradable up to 1GB RAM & 16GB eMMC

LCD :

3.5" TFT LCD with 320 x 480 Resolution, 500 NIT, 16-Bit RGB

Touch :

Scratch Resistant Multi-Point Capacitive Touch Screen with 6H Toughen Glass

Keypad :

NA

Camera :

NA

Operating System :

BOSS OS or Linux Debian with Secure Boot

LED Indicators :

Battery Charging Status, User Defined

Audio :

1W, 8 Ohm Speaker for Announcements

RTC :

Yes (Coin Cell, On Board Reachargabale )

Operating Temperature :

0 Deg - 60 Deg C

Storage Temperature :

0 Deg - 70 Deg C

Operating Humidity :

10%-90% RH (Non-Condensing)

Dimensions :

(L x W x H) 86.29 mm x 40.40 mm x 214.61 mm

Weight :

Approx 550 grams

Certifications :

CE, RoHS, BIS, IP65

Fingerprint Sensor

Fingerprint Type :

Scratch Free Optical Sensor

Fingerprint Image :

316 x 354 Pixels ( 16 x 18 mm )

Image Specs :

500DPI, 8 Bit Grayscale

Certifications :

CE, FCC, RoHS, STQC, PIV, IEC60950, IS13252 Part I

Smart Card Reader

Contactless Card :

ISO14443 Type A/B Cards & SCOSTA Card Support, 424 Kbps or other lower speed, Antenna should read from 50mm read range.

SAM :

ISO7816 Class A

Interfaces

Ethernet :

10/100 Mbps, Through Aux Connector

SAM Socket :

1 x SAM Socket On Board

DC Jack :

1 x DC Power Input, through AUX connector

RS-485 (Development Only) :

1 Host or Slave (Selectable), Through Aux Connector

Wiegand :

2 Input ; 2 Output , Through Aux Connector, OSDP & Support all bit format

GPIO :

3V TTL 1 x Output, 1 x Input, Through Aux Connector

Relay :

Two (5V/2A) Relay with Non-Potential Contacts (NC, NO, COM as Output), Through Aux Connector

Micro USB :

4-Pin Micro USB, Through Aux Connector (Development Only)

USB OTG :

5 Pin On Board USB Connector for Finger Print Module

Electrical

Power Adaptor :

Input AC: 100~280V, 47Hz to 53Hz; Output DC: 5V/3.0A

Battery Back-Up :

Li-Po 4000 mAH Rechargeable & Replaceable Battery
