Get In TouchEnhance security and compliance with our cutting-edge breath analyzer, integrated with advanced facial recognition technology. Designed for identity-based access control systems, this device offers accurate alcohol level detection and secure identity verification. Ideal for high-security areas, it ensures only authorized, sober personnel gain access, reducing risk and promoting safety. Streamline your security protocol with this reliable, innovative solution.
Some of the significant features of our advance biometric fingerprint scanner device are listed underneath:-
IP65
CE Certification
ROHS Certification
Liveness Check Passed
Dual RGB and Near Infrared Camera 2 Million WDR Pixel Resolution
2.2GHz Quad core ARM Cortex-A73
2GB RAM + 16GB eMMC
5 Inch, Vertical Screen H 375 * W 127 Resolution Multi point capacitive touch screen with tuffen glass
Integrated Personal Auth and Analyzing System AI Enabled with Integrated EDHMS.
Feature exquisite specifications that are designed to address the modern-day requirements of individual identification and authentication.
CPU :
2.2GHz Quad core ARM Cortex-A73 and 1.8GHz dual core Cortex-A53
GPU :
ARM G52 MP4 GPU
RAM Memory :
2GB
Storage Memory :
16GB
Display
5 Inch, 1080X1920 Resolution, Full view IPS TFT Display
Touch
Multi point capacitive touch screen with tuffen glass
Camera Type :
Dual RGB and Near Infrared Camera
Pixel Resolution :
2M (1920 x1080)
Frame Rate :
30 FPS
Minimum Illumination :
0.1 LUX
Dynamic Range :
45dB Linear & 100 dB HDR supported for various light environment
Focus Distance :
30 -150 cm
White Balance :
Auto
Photo Flood Light :
Visible & IR dual Flood Light
Support :
Live Face Detection
Network Module :
1x RJ45, 10M/100M
Wi-Fi / BT :
Supported
Audio :
Supported
HDMI :
1 X HDMI
RS232 :
1 x RS232
RS485 :
1 x RS485
Wiegand Interface :
1 x Output ; 1 x Input
Relay Interface :
2 x Relay (NC, NO, COM)
Power Jack :
DC 12V/2A
Supervised Input(Configurable) :
IN0- Egress, IN1- Emergency, IN2- Fire
Supervised Output (Configurable) :
Out0- Rev, Out1-Rev
RTC :
Supported
2G/3G/4G :
Supported (Optional)
Face Detection :
Support multiple people detection and tracking
Face Database Capacity :
20000 / 50000
1:N Face Recognition :
Supported (20K, 50K)
1:1 Face-matching :
Supported
Stranger Detection :
Supported
Face Recognition Accuracy :
Normal Light Condition > 99.9%
External Light Condition > 95%
Liveness Detection :
Supported
Recognition Speed :
300 ms
Operating System :
Customized Android / Linux
SDK :
Appropriate SDK for all accessories to be provided
Accuracy :
+/- 0.005%BAC at 0.100%BAC
Sensor :
Replaceable fuel cell type alcohol sensor
Mouthpiece :
No need to use
Warm up time :
3 seconds ~ 4 minutes
Response time :
Within 3 seconds at 0.00%BAC
Within 10 seconds at 0.10%BAC
Casing :
Stainless steel bottom plate with ABS top enclosure
Protection Grade :
Dust Proof
Operating Temperature :
- 10℃ ~ 60℃
Storage Temperature :
- 20℃ ~ 60℃
Operating Humidity :
10%-90% RH (Non-Condensing)
Dimensions :
375.0 x 127.0 x 132.0 mm
Weight :
2000g ~ 2200g
Mounting Type :
Wall Mount
Certifications :
CE, RoHS, BIS, IP54, IK00
Comprehensive user guides and informative brochures available, providing a detailed overview and usage instructions.
