MBAS10L1 Aadhaar Enabled Biometric Attendance System

The MBAS10 is a reliable Aadhaar-enabled biometric attendance system designed to streamline and secure workforce attendance management. With L1 certification, it complies with UIDAI standards, ensuring secure and accurate Aadhaar-based authentication, making it an excellent choice for government and private organizations.

Get In Touch

Our MBAS10 L1 Aadhaar Enabled Biometric Attendance System

With the aid of an advanced biometric algorithm and PIV/STQC L1 certified FAP10 scratch-free optical biometric fingerprint sensor, Mantra's 7" L1 AEBAS Device MBAS10 is created to meet the need for precise individual identification for various applications like eKYC, Banking and Time Attendance.

The MBAS10 can be used as a wall-mounted device for time-attendance applications. The device's capacitive scratch-resistant touch screen with 6H toughened glass, and optimized thermal management makes it very robust. The latest biometric technology is used by MBAS10 to authenticate and identify users using their own fingerprint impressions. With built-in 3G, Ethernet, wireless, & GPS, the device displays increased connectivity, along with the 4,000 mAh battery with auto sleep & wakeup functionality increases battery backup.

Applications

Time-Attendance

Canteen Management

Banking & Finance

Resource & Manpower Management

School Bus Management & Tracking

Insurance Claim Processing

eKYC

Our Specifications

Hardware & System

CPU :

ARM Cortex A7 @1.3GHz Quad Core Processor

Memory :

1GB RAM + 8GB Flash

LCD :

7" TFT LCD with 1024x600 Resolution

Touch :

Scratch Resistant Multi-Point Capacitive Touch Screen with 6H Toughen Glass

Operating System :

Android 8

Camera :

5MP Auto Focus Front Camera with Flash LED

LED Indicators :

Power On/Off, Battery Charging Status

Audio :

High-Quality 1W Speaker for Announcements

RTC :

Yes

Object Detection sensor :

IR based Proximity sensor for device auto sleep & Wakeup

Control Buttons :

1x Power On/Off, 1x Reset Key

Operating / Storage Temperature :

0 Deg - 50 Deg C

Operating Humidity :

10%-90% RH (Non-Condensing)

Dimensions :

221 x 181 x 48mm

Weight :

Approx 0.8Kg ( Depend Upon Configuration )

Certifications :

CE, RoHS, BIS, IP54

Fingerprint Sensor

Fingerprint Type :

Scratch Free Optical FAP10 L1 Sensor

Fingerprint Image :

276 x 336 Pixels

Image Specs :

500 DPI +/- 2%, 256 (8 - Bit Gray Level)

Certifications :

CE, FCC Part 15B, RoHS, STQC L1, FBI PIV, EN/IEC 62368-1, IS 13252 (Part 1)

Interfaces

3G/GPRS :

2G (900/1800), 3G (B1/B8)

Wi-Fi :

IEEE 802.11 b/g/n with Flex antenna

Ethernet :

10/100 Mbps

SD Card :

MicroSD Card (Supports up to 32GB)

Bluetooth :

BT + BLE 4.2

GPS :

16 Channel NMEA Compliant with Flex Antenna, AGPS Supported

SIM Socket :

1 x SIM Socket

DC Jack :

1 x DC Power Input

Micro USB :

1 Micro USB Port for PC Connection as debug port

Electrical

Power Adaptor :

Input AC: 90 ~ 265V, 50Hz ; Output DC: 12V/2A

Battery Pack :

Li-Ion 4000 mAH Rechargeable & Replaceable Battery

Our Downloads

Access comprehensive guides and brochures for detailed insights and optimal usage.

Product Brochure
