MARC10 Module : MOPvC10

MARC10 is a reliable, secure and easy to use fingerprint module utilized for an accurate identification, verification and authentication process of an individual.

Get In Touch Download Brochure

Our MARC10 Module

MARC10 captures high-resolution fingerprint images with the most rugged and advanced capacitive sensor. Our MARC10 fingerprint module is an advanced capacitive sensor. The module supports MINEX compliance extractor and is made up of a scratch-free sensor surface.


Some of the significant features of our advance biometric fingerprint scanner device are listed underneath:-

Scratch free sensor surface

Latent Finger Detection

Lowest FAR and FRR

USB 2.0 interface with plug and play

500 DPI Capacitive fingerprint sensor

Support Windows, Android, Linux

FAP10 Capacitive Sensor

IP54 water and dust protection


MARC10 feature exquisite specifications that are designed to address the modern-day requirements of individual identification and authentication.

Parameters Specification
Fingerprint Sensor Type: FAP10 Capacitive Sensor
Pixel Resolution: 500 dpi +/- 2%
Platen size: 12.8mm x 18mm
Image Size: 256 x 360 Pixels
Image Grayscale: 256 Gray Level (8 - Bit Image)
Maximum Acquisition Time (Placement to Template): < 2 sec
FRR & FAR: < 0.1% & < 0.001%
Module Approx. Dimension (L x W x H): 35mm X 23mm X 5mm
Approx Weight: 0.010 Kg
Capture mode: Auto Finger detection functionality & Auto capture with built-in quality check (Incorporates NIST quality considerations)
Latent Finger Detection: Supported
MTBF: 50000 Hours
Wear & Tear cycle of sensor: 1 Million
Cross Cut: 5B
Surface Hardness: 7H
SALT Spray Test: IEC 60068-2-11/IS 9844/ASTM G 85
Parameters Specification
Protocol: USB2.0 , SPI (Up to 24 Mbps), UART (Baud Rate- Default 9600, Up to 115200)
Connector: Module: Wire to Board **
Parameters Specification
Operating Voltage: +5.0V ±5% (USB/UART Powered Device)
: +3.3V±3% (Only for SPI Powered Device)
Current Consumptions: Operating Current: < 50 mA & Standby Current : < 30 mA
Parameters Specification
Operating Temperature: -10°C to +70°C
Storage Temperature: -20°C to +85°C
Humidity (Operating / Storage): < 90% RH, Non-condensing
Parameters Specification
Biometric Data Interchange Format: ISO 19794-2 : 2005 & 2011 and ANSI 378
: ISO 19794-4 : 2005 & 2011, WSQ3.1
EMI / EMC Compliance: CE & FCC Part 15B class A
ESD protection: Contact Discharge: +/- 8kV, Air Discharge: +/- 15kV
Environmental, Health and Safety: RoHS
Safety: EN/IEC 62368-1, IS 13252 (Part 1)
Image Quality: FBI PIV Certification, Mobile-ID FAP10
IP Rating: IP67 (Platen Area)
Device Driver: WHQL certified driver
Parameters Specification
Operating System: Windows 7, 10 & 11, Android & Linux
Standard Software/SDK: 1:1 Matching: MORFIN_AUTH,
: 1:N Matching: MORFIN _SEARCH

** FPC Connector available for USB, UART & SPI interface
