MFS211Optical Fingerprint Scanner

The MOSIP-certified MFS211 Fingerprint Authentication Device is engineered for secure and reliable identity verification. Its seamless integration capabilities make it an ideal solution for MOSIP systems, ensuring efficient and accurate authentication for diverse applications.

Get In Touch

Our MFS211 Optical Fingerprint Sensor

The MFS211 Fingerprint Authentication Device is MOSIP-certified, delivering robust and secure identity verification. Designed for seamless integration into MOSIP systems, it offers unmatched reliability and precision in authentication. This biometric device is ideal for applications across government, banking, and enterprise sectors, ensuring compliance and efficiency in operations. With advanced fingerprint scanning technology and a user-friendly interface, the MFS211 stands as a dependable choice for secure identity management, catering to organizations prioritizing accuracy and MOSIP compatibility.

Applications

Banking

Corporates

Public distribution system

Payment

Institution

Merchant Payment

E-Governance

Specification

MFS210 feature exquisite specifications that are designed to address the modern-day requirements of individual identification and authentication.

Sensor

Fingerprint Sensor Type :

Scratch Free Optical Sensor

Pixel Resolution :

500 DPI +/- 2%

Sensing Area :

15.24mm x 20.32mm (0.6 x 0.8 Inch)

Image Size :

300 x 400 Pixels

Image Grayscale :

256 (8 - Bit Gray Level)

FRR & FAR :

< 0.1% & < 0.001%

Maximum Acquisition time :

< 2 Sec( Placement to Template )

Capture mode :

Auto Finger detection functionality & Auto capture with built-in quality check (Incorporates NIST quality considerations)

Illumination Source :

RED LED

Security

Crypto operation :

Hardware base RSA2048 Key Generation, AES-GCM-256, SHA-256, TRNG support

Secure Memory :

TEE support by the device. Secure memory support key wraping feature

Secure Boot :

Secure boot support by the device

Electrical

Protocol :

USB 2.0

Operating Voltage :

5V ±5% (USB Powered Device)

Operating Current :

Operating Current: < 100 mA & Standby Current : < 50 mA

Environmental

Operating Temperature :

-10°C to +70°C

Storage Temperature :

-20°C to +85°C

Humidity (Operating / Storage) :

< 90% RH, Non-condensing

Compliant to Following Standard

Biometric Data Interchange Format :

ISO 19794-2 : 2005 & 2011 for minutiae,

ISO 19794-4 : 2005 & 2011 for Image Template in Encrypted mode

*EMI / EMC Compliance :

CE & FCC Part 15B class A

*ESD protection :

Contact Discharge: +/- 8kV,

Air Discharge: +/- 15kV

*Environmental, Health and Safety :

RoHS

*Safety :

EN / IEC 62368-1, IS 13252 (Part 1)

*Image Quality :

FBI PIV Certification, STQC

*IP Rating :

IP65

Device Driver :

WHQL certified

*USB Interface :

USB-IF Certified

Dimensions

Device Dimensions (L x W x H) :

68 x 56.5 x 31.5 mm

Device Weight :

105 grams

Module Dimensions (L x W x H) :

44.10 x 38 x 28.7 mm

Module Weight :

35 grams

System Requirements

Operating System

: Windows - x86 & x64, Android - 7 & Above

Standard Software/SDK

MOSIP Compliant

* Certification under process
