MIS100V2 IRIS Scanner

STQC certified USB IRIS scanner with proprietary auto-capture, JPEG2000 ISO/IEC 19794-6 output, and sub-2-second capture - deployed across Aadhaar, AEBAS, Jeevan Pramaan, NREGA, and banking identity programs.

Aadhaar UIDAI AEBAS Jeevan Pramaan NREGA Banking KYC PDS

Get a Quote Download PDF

STQC Certified

<2 sec Capture

Key Highlights

Accurate IRIS Recognition for Identity Programs

MIS100V2 leverages proprietary distance sensing and focus analysis for fast, accurate iris capture - delivering STQC-certified performance across government welfare, banking, and access control deployments.

STQC Certified IRIS Sensor

ISO/IEC 19794-6 | JPEG2000

STQC certified high-resolution CMOS iris sensor outputs ISO/IEC 19794-6 compliant JPEG2000 compressed images (KIND1-KIND7). Proprietary quality algorithm flags and rejects poor iris images before capture, ensuring every scan meets compliance standards.

Sub-2-Second Auto Capture

Proprietary Distance Sensing

MIS100V2's proprietary distance sensing and focus analysis technology enables fast auto-capture with built-in quality checking - capturing a compliant iris image in under 2 seconds, even for first-time users unfamiliar with iris scanning.

700-900 nm Imaging Wavelength

NIR | 8-bit Pixel Depth

Near-infrared imaging at 700-900 nm captures iris texture invisible to the naked eye - providing consistent, high-contrast images regardless of iris colour. 8-bit pixel depth and >10 pixels/mm resolution ensure accurate pattern matching.

USB 2.0 / USB 1.1 | Cross-Platform

Windows | Android | Linux

Plug-and-play USB 2.0 / 1.1 connectivity with drivers for Windows XP, Win7, Win2008, Android, Linux, and Embedded Linux - making MIS100V2 compatible with existing government and enterprise IT infrastructure without hardware upgrades.

ESD & EMC Protected

IEC 62471 | FCC | RoHS

ESD protection to 8KV air discharge and 4KV contact. FCC Part 15B / CISPR 22 Class B radiated emission compliance and IEC/EN 61000-4-3 immunity. RoHS compliant and IEC 62471 safety exempt group rating for safe IR LED operation.

Proven Across Government Programs

UIDAI | Jeevan Pramaan | NREGA | PDS

Widely deployed across India's most demanding biometric programs - Aadhaar authentication, AEBAS attendance, Jeevan Pramaan pension verification, NREGA rural employment, PDS food distribution, and Skill Development initiatives.

More Details

Built for Accurate IRIS Identity Programs

MIS100V2

STQC Certified IRIS Scanner

Imaging Wavelength

700-900nm

Near-Infrared imaging | 8-bit pixel depth | >10 pixels/mm resolution

Capture Speed

<2 sec

Proprietary distance sensing | auto-capture

Standard

ISO 19794-6

JPEG2000 compressed | KIND1-KIND7 compliant

Certification

STQC

IEC 62471 | FCC | RoHS | ESD 8kV air

Protection

8kV

ESD Air Discharge protection

Interface

USB 2.0

USB 1.1 compatible | Windows | Android | Linux

Applications

Deployed Across India's Identity Programs

MIS100V2 powers IRIS-based authentication for welfare delivery, banking, access control, and government attendance systems.

Aadhaar | UIDAI | AEBAS

Aadhaar UIDAI & AEBAS Authentication

Contactless IRIS capture provides tamper-proof identity verification for government attendance, welfare delivery, and Aadhaar-linked programs.

Welfare | NREGA

Jeevan Pramaan & NREGA Life Certificate

Hygiene-friendly touchless IRIS eliminates proxy pensioners and ensures authentic proof-of-life for door-step banking and rural welfare schemes.

Enterprise | Security

High-Security PC & Network Authentication

Replace passwords and tokens with contactless IRIS for Windows login, VPN access, and privileged-user authentication across secure enterprise networks.

Healthcare | Medical ID

Healthcare & Medical Patient Identity

Contactless IRIS prevents patient misidentification in hospital workflows, pharmacy dispensing, and Ayushman Bharat health scheme verification.

Specifications

Technical Details

Complete specifications for system integrators, procurement officers, and IT managers.

Imaging Specifications

Spatial Resolution

50% 1.0 LP/mm

Pixel Resolution

> 10 pixels/mm

Image Margins - L & R

0.6 * iris radius

Image Margins - T & B

0.2 * iris radius

Imaging Wavelength

700-900 nm (Near Infrared)

Pixel Depth

8 bits/pixel

Output Image Format

KIND1-KIND7 with JPEG2000 Compression (ISO/IEC 19794-6)

Capture & Safety

Capture Mode

Auto Capture with Built-in Quality Check

Capture Time

< 2 seconds

Safety

Safety Exempt Group per IEC 62471:2006-07

Health & Safety

RoHS Compliant

EMC & Connectivity

ESD Air Discharge

8 KV

ESD Contact Discharge

4 KV

Radiated Emission

FCC Part 15B / CISPR 22 Class B

Radiated Immunity

IEC/EN 61000-4-3:2006+A2:2010

Connectivity

USB 2.0 / USB 1.1

Operating System

Windows XP, Win7, Win2008, Android, Linux, Embedded Linux
