BioNIC Xtreme FX Elegant and Secure Facial Authentication Terminal

CPU :

2.2GHz Quad core ARM Cortex-A73 and 1.8GHz dual core Cortex-A53

GPU :

ARM G52 MP4 GPU

RAM Memory :

2GB

Storage Memory :

16GB

Display

5 Inch, 1080X1920 Resolution, Full view IPS TFT Display

Touch

Multi point capacitive touch screen with tuffen glass

Network Module :

1x RJ45, 10M/100M

Wi-Fi / BT :

Supported

Audio :

Supported

HDMI :

1 X HDMI

RS232 :

1 x RS232

RS485 :

1 x RS485

Wiegand Interface :

1 x Output ; 1 x Input

Relay Interface :

2 x Relay (NC, NO, COM)

Power Jack :

DC 5V/3A

Supervised Input(Configurable) :

1. Egress Switch,
2. Fire Alarm,
3. Emergency Switch,
4. Lock Down Switch

Supervised Output (Configurable) :

1. Alarm

RTC :

Supported

Contactless Card (Optional) :

ISO14443 Type A/B Cards, Mifare Classic / Desfire

Camera Type :

Dual RGB and Near Infrared Camera

Pixel Resolution :

2M (1920 x1080)

Frame Rate :

30 FPS

Minimum Illumination :

= 0.1 LUX

Dynamic Range :

= 45dB Linear & = 100 dB HDR supported for various light environment

Focus Distance :

30 -150 cm

White Balance :

Auto

Photo Flood Light :

Visible & IR dual Flood Light

Support :

Live Face Detection

Face Detection :

Support multiple people detection and tracking

Face Database Capacity :

10000 / 50000

1:N Face Recognition :

Supported (5k, 10k, 20K, 50K)

1:1 Face-matching :

Supported

User & Log Capacity :

1M

Stranger Detection :

Supported

Face Recognition Accuracy :

Normal Light Condition > 99.9%

External Light Condition > 95%

Liveness Detection :

Supported

Recognition Speed :

300 ms

Sim Card Slot :

Nano SIM card slot

Speed :

150Mbps Download/50Mbps Upload

Antenna support :

1*4G Main , 1*4G DIV , 1 X GPS

Transmission Rate :

150Mbps

Operating System :

Customized Android / Linux

SDK :

Appropriate SDK for all accessories to be provided

Casing :

Light weighted oxidised aluminium alloy back cover for heat dissipation

Protection Grade :

Dust Proof

Operating Temperature :

- 10℃ ~ 60℃

Storage Temperature :

- 20℃ ~ 60℃

Operating Humidity :

10%-90% RH (Non-Condensing)

Dimensions :

185.0 x 97.0 x 30.5 mm

Weight :

Approx 500 gm

Mounting Type :

Wall mount, Turns Tile Mount

Certifications :

CE, RoHS, BIS
