BioNIC Xtreme XI Enterprise Facial Terminal

CPU :

2.2GHz Quad core ARM Cortex-A73 and 1.8GHz dual core Cortex-A53

GPU :

ARM G52 MP4 GPU

RAM Memory :

2GB

Storage Memory :

16GB

Display

5 Inch, 1080X1920 Resolution, Full view IPS TFT Display

Touch

Multi point capacitive touch screen with tuffen glass

Network Module :

1x RJ45, 10M/100M

Wi-Fi / BT :

Supported

Microphone :

Diameter of Microphone ~1cm

Speaker :

8O/2W * 1 with 50cm cable

RS232 :

1 x RS232

RS485 :

1 x RS485

USB OTG :

USB type A * 1; Micro USB * 1

Wiegand Interface :

1 x Output ; 1 x Input

Relay Interface :

2 x Relay (NC, NO, COM)

Power Jack :

DC 12V/2A

Supervised Input(Configurable) :

1. Egress Switch,
2. Fire Alarm,
3. Emergency Switch,
4. Lock Down Switch

Supervised Output (Configurable) :

1. Alarm

RTC :

Supported

PoE :

Supported

Contactless Card (Optional) :

ISO14443 Type A/B Cards, Mifare Classic / Desfire

Contact Card Slot (Optional) :

ISO 7816 A/B/C, Supported

Camera Type :

Dual RGB and Near Infrared Camera

Pixel Resolution :

2M (1920 x1080)

Frame Rate :

30 FPS

Minimum Illumination :

= 0.1 LUX

Dynamic Range :

= 45dB Linear & = 100 dB HDR supported for various light environment

Focus Distance :

30 -150 cm

White Balance :

Auto

Photo Flood Light :

Visible & IR dual Flood Light

Support :

Live Face Detection

Face Detection :

Supported Face Recognition with Mask

Face Database Capacity :

20000

1:N Face Recognition :

Supported (5000)

1:1 Face-matching :

Supported (20000)

Users & Log Capacity :

1M

Stranger Detection :

Supported

Face Recognition Accuracy :

Normal Light Condition > 99.9%

External Light Condition > 95%

Liveness Detection :

Supported

Recognition Speed :

300 ms

Sim Card Slot :

Nano SIM card slot

Speed :

150Mbps Download/50Mbps Upload

Antenna support :

1*4G Main, 1*4G DIV, 1 X GPS

Transmission Rate :

150Mbps

Operating System :

Customized Android

SDK :

Appropriate SDK for all accessories to be provided

Casing :

ABS

Protection Grade :

Dust & Water Proof

Operating Temperature :

- 10℃ ~ 60℃

Storage Temperature :

- 20℃ ~ 60℃

Operating Humidity :

10%-90% RH (Non-Condensing)

Dimensions :

~269 X 138 X 40 mm

Weight :

~950 gm

Mounting Type :

Wall-mounted /Pole-Mounted/e-Gate

Certifications :

CE, RoHS, IP65, BIS, FCC, UL
