MFS210Biometric Authentication Device FAP20

The FAP20 MFS210 is a cutting-edge biometric authentication device designed for Aadhaar and secure identity verification. Its advanced technology ensures reliable performance, making it ideal for use in government, banking, and corporate applications requiring precise and efficient authentication.

Get In Touch

Our MFS210 Optical Fingerprint Sensor

The FAP20 MFS210 Biometric Authentication Device is Aadhaar-compliant and designed for secure identity verification. Its robust fingerprint scanning technology ensures accurate and reliable authentication, making it a trusted choice for government schemes, banking operations, and corporate environments. With its advanced features and ease of integration, the MFS210 delivers unmatched performance in managing identity and access control needs. This device is perfect for organizations prioritizing security, accuracy, and compliance with India's unique identification standards.

Applications

Banking

Corporates

Public distribution system

Payment

Institution

Merchant Payment

E-Governance

Specification

MFS210 feature exquisite specifications that are designed to address the modern-day requirements of individual identification and authentication.

Sensor

Fingerprint Sensor Type :

Scratch Free Optical Sensor

Pixel Resolution :

500 DPI +/- 2%

Sensing Area :

15.24mm x 20.32mm (0.6 x 0.8 Inch)

Image Size :

300 x 400 Pixels

Image Grayscale :

256 (8 - Bit Gray Level)

FRR & FAR :

< 0.1% & < 0.001%

Maximum Acquisition time :

< 2 Sec( Placement to Template )

Capture mode :

Auto Finger detection functionality & Auto capture with built-in quality check (Incorporates NIST quality considerations)

Illumination Source :

RED LED

Security

Crypto operation :

Hardware base RSA2048 Key Generation, AES-GCM-256, SHA-256, TRNG support

Secure Memory :

TEE support by the device. Secure memory support key wraping feature

Secure Boot :

Secure boot support by the device

Electrical

Protocol :

USB 2.0

Operating Voltage :

5V ±5% (USB Powered Device)

Operating Current :

Operating Current: < 100 mA & Standby Current : < 50 mA

Environmental

Operating Temperature :

-10°C to +70°C

Storage Temperature :

-20°C to +85°C

Humidity (Operating / Storage) :

< 90% RH, Non-condensing

Compliant to Following Standard

Biometric Data Interchange Format :

ISO 19794-2 : 2005 & 2011 for minutiae,

ISO 19794-4 : 2005 & 2011 for Image Template in Encrypted mode

*EMI / EMC Compliance :

CE & FCC Part 15B class A

*ESD protection :

Contact Discharge: +/- 8kV,

Air Discharge: +/- 15kV

*Environmental, Health and Safety :

RoHS

*Safety :

EN / IEC 62368-1, IS 13252 (Part 1)

*Image Quality :

FBI PIV Certification, STQC

*IP Rating :

IP65

Device Driver :

WHQL certified

*USB Interface :

USB-IF Certified

Dimensions

Device Dimensions (L x W x H) :

68 x 56.5 x 31.5 mm

Device Weight :

105 grams

Module Dimensions (L x W x H) :

44.10 x 38 x 28.7 mm

Module Weight :

35 grams

System Requirements

Operating System

: Windows - x86 & x64, Android - 7 & Above

Standard Software/SDK

UIDAI & STQC Certified L1 RD Service

* Certification under process
